Dante Over IP Clothing Store   ATEN Solution Diagram

 (BGM with Network Player / Paging)



























            Dante Expansion Card

               AP901 Dante

                                                   •   Enhance AP2 Series AMP with Dante compatibility.
                                                   •   Supports 44.1k / 48kHz Sampling Rate.
 Application  Ideal for audio management of retail stores in shopping center.  •   Offering a straightforward and dependable AoIP solution.




 ATEN  ① Immersive Background Music: Elevate the music experience with 7 AS104 speakers and 2 AS106,
 Solution  powered by AP206. The DSP-filtered high frequency is output in low impedance mode, ensuring   2x60W Power Amplifier with DSP
 optimal sound quality and creating a layered music atmosphere that enhances the overall   AP206
 ambiance and elevates the customer experience.    •   2x60W Class D Power Amplifier with integrated professional DSP.

 ② Centralized Management: Integrate AP901 with AP206 to receive audio from Dante Over IP   •   Intuitive Web GUI simplifies DSP configuration.
 devices. This allows the shopping center's control center to centrally manage audio across retail
 stores, maximizing cost-effectiveness and simplifying audio management operations. Enjoy   •   Power supply with PFC for enhanced efficiency, compatible with
 seamless audio control and enhanced efficiency.      ATEN VK control units for energy-saving and automation.
                                                   •   Flexible expansion slot design for versatile application scenarios.



            60W Mono Hi-Z Power Amplifier

               AP106
                                                   •   A Class D power amp offering 60W power to 70V or 100V
                                                      audio systems.
                                                   •   Inbuilt 2-band shelf EQ for 6 dB treble and bass control.
                                                   •   Power Saving Mode – shuts down with -50 dBu or less audio
                                                      input for 30 mins and reactivates at -30 dBu.
                                                   •   Integrated protection – safeguards against amp shortcuts,
                                                      output voltage variations, high-frequency overload, and
                                                      overheating.
