Presentation Switches for Education Applications ATEN Solution Diagram

ATEN offers different types of presentation switches to provide multiple learning
solutions to meet the needs of educational applications at all levels and to
promote synchronous learning participation and collaboration.

Hybrid Learning

A college that offered business classes for professionals was looking to boost the efficiency and
Background
impact of its teaching presentations with a solution that provided multi-format connectivity as
well as remote teaching functionality when required.
4 x 2 True 4K Presentation
Matrix Switch with Scaling, DSP, and
HDBaseT-Lite
① Control switching of various sources from easily accessible areas, as well as support for
Key
Requirements remote projectors and displays. VP1421
② Live and loop playback of educational presentations as needed in the classroom.
③ Support for microphone input and flexibility to mix with other audio sources during live
classes.

• Multi-format AV Switching – switch among 1 HDBaseT, 2 HDMI and 1 VGA inputs to 1 HDBaseT and 1 HDMI
outputs and support for audio DSP.
① VP1421 supports long-distance signal transmission via HDBaseT.
ATEN HDBaseT-Lite technology – extends uncompressed AV, IR, RS-232, and power over one Cat 6/6a cable up to
Solution ② VP1421 features a embed / de-embed audio function that allows direct intra-class switching •
of sources via a touch-closed remote control panel. 70m.
③ UC9020 allows for capturing, editing, streaming, and switching between teaching • Superior video quality – True 4K resolutions up to 4096 x 2160@60Hz (4:4:4) (HDMI) / 4096 x 2160@60Hz
presentation content and the in-class camera, and combines these two input sources into a (4:2:0) (HDBaseT); HDR support.
livestream controlled via an iPad. • Scaler – supports video upscaling to 4K for display A and downscaling to 1080p for display B.
