ATEN Solution Diagram

Conference Room
Speaker TV TV

HDMI RS-232 USB Soundbar HDMI RS-232
Audio USB
Teams HDBaseT (PoH) Wireless Router
VE802R VE802T VE802R
PC
HDBaseT (PoH) HDMI RS-232
HDMI
Network
HDMI
Room Booking System
VP3520
HDBaseT (PoH) HDBaseT (PoH)

VE2812AEUT VE2812AEUT VP2020 VK0100
HDMI
VGA Audio

Laptop Laptop Keyboard / Mouse
Bringing together members from different locations and regions for meetings, suitable for Video Control USB Audio Network HDBaseT
Background
cross-team or multinational enterprises, this type of meeting space is increasingly in demand.

5 x 2 True 4K Seamless
① Real-time source switching and stable transmission of high-definition signals for smooth
Key presentations in meetings with both local and remote participants.
Requirements Presentation Matrix Switch
② Keep communication smooth with microphone systems that allow both local and remote with Control
participants to hear the conversation clearly.
VP3520
③ Convenient and intuitive operation that allows participants to start the conference
equipment and enter the discussion instantly.

① VP3520 provides control of displays, long-distance HDBaseT transmission, and audio delivery.
ATEN
Solution ② ATEN audio system provides the microphone and source audio and shares it with the • Superior video quality – True 4K resolutions up to 4096 x 2160 @ 60 Hz (4:4:4) (HDMI) / 4096 x 2160 @ 60
connected local and remote participants with stunning clarity. Hz (4:2:0) (HDBaseT).

③ Remote conference sharing can be achieved via a third-party UC Conference System; in • 4K Scaler – features a 4K video scaler to convert input resolutions to the optimum display resolutions.
addition, screen sharing and briefings can both be displayed for discussion smoothly.
• Auto display on / off control – supports display control through CEC, IR, RS-232, PJLink and controls
④ Customized AV Controls can be used in the VP Series to control the connected AV
equipment via the front panel pushbuttons. projector screen through relay port.
• Audio amplifier – 2 x 10 W built-in power amplifier with speaker outputs on terminal block connectors.
