ATEN Solution Diagram












                    Lecture Hall                                                                                                                       Screen                    Screen                    Screen



                                                                                                                                                       Projector                 Projector                 Projector

                                                                                                                                                                HDMI              HDMI              HDBaseT






                                                                                                                                                                              VP2730
                                                                                                                                                      DP
                                                                                                                                                             HDMI           VGA          HDMI          Audio       Audio







                                                                                                                                                 PC (DP)     Laptop        Laptop       Set-top Box  Microphone System  Amplifier

                                                                                                                                                                        Video   Audio  HDBaseT






                           Lecture halls are large scale classroom settings and are used primarily for university classes. The
               Background                                                                                                          7 x 3 Seamless Presentation Matrix Switch
                           importance of a lecture hall is that, first and foremost, it operates as a centralized presentation
                           space to convey content information to as large an audience as possible all at once.                    with Scaler, Streaming, Audio Mixer, and HDBaseT



                                                                                                                                     VP2730
                           ① The display can be located at a maximum distance of 70 meters away, and there must be no
                  Key         black screen but instead smooth switching of the signal source.
              Requirements
                           ② Audio needs to be extracted and connected to the venue audio system, and the sound
                              needs to be clearly audible.
                           ③ Overlay the microphone input on top of other audio sources to enrich the presentation.

                                                                                                                                   •   Ultra Seamless Switching with Scaler – zero second switching without any latency while scaling for the best

                           ① VP2730 supports long-range expansion via HDBaseT with zero-second seamless switching of                   output resolution ensures extra smooth presentations.
                 ATEN         display content between sources.
                Solution                                                                                                           •   Bi-directional Distance-free Streaming – go live to stream out HD video to up to 5 remote sites or stream in
                           ② VP2730 has audio embedding and de-embedding capabilities and can be mixed with any                        content from a remote site via an intuitive web GUI.
                              external analog or digital audio source with microphone input.
                                                                                                                                   •   Built-in Audio Mixer – supports dynamic / condenser microphone input with selectable 48V Phantom Power
                                                                                                                                       and allows mic input to be mixed with program audio.

                                                                                                                                   •   Multi-view Flexibility – display and switch simultaneously up to six sources on PiP (picture in picture) PbP
                                                                                                                                       (picture by picture), quad-view, and more.
