Get the Most out of a Hybrid 3-in-1 Solution! Suggested ATEN HDBaseT Receivers:

Receiver Model VE2812R VE1812R VE814AR VE811R VE801R VE802R VE601R VE901R
Switch Extend Convert Photo

Between 1080p up to From HDMI / VGA
VGA & HDMI 150m / 4K to DVI /
inputs up to 100m HDMI / DP HDMI
Video Output (audio de- HDMI HDMI *2 HDMI HDMI HDMI DVI DisplayPort
embedding)
IR/RS-232 IR/RS-232 IR/RS-232 IR/RS-232 N/A N/A IR/RS-232 N/A N/A

Suggested ATEN PSE Devices:
HDBaseT 1.0 Class A 1.0 Class B
VP1421 VE44PB
4 x 2 True 4K Presentation Matrix Switch 4-Output PoH/PoE Power Injector
Transmission 4K up to 100m ; 4K up to 40m ;
2 HDMI, 1 VGA, 1 HDBaseT inputs to Power up to 4 ATEN PoH/PoE products Distance 1080p up to 150m (Long Reach Mode enable) 1080p up to 70m
1 HDMI, 1 HDBaseT outputs Supports HDBaseT connectivity
Built-in audio DSP Supplies 15.4W power / port
IR, RS-232, Ethernet control Assured signal quality (with 80% Long Reach Mode Yes N/A
Supports PoH original transmission distance)
