Connection HDBaseT (Class B)
Video Interface DisplayPort HDMI DVI
Model VE901 VE1830 VE801 VE802 VE805R VE601


Inputs to Outputs 1 to 1 1 to 1 1 to 1 1 to 1 1 to 1 1 to 1
1920 x
Max. Resolution / 4K@40m; Ture 4K@40m; 4K@40m; 4K@40m;
Distance 1080p@70m 1080p@70m 1080p@70m 1080p@70m 1080p@70m 1200@40m;
1080p@70m
HDR N/A • N/A N/A N/A N/A
HDCP 1.4 2.2 2.2 2.2 1.4 1.4
Audio • (DisplayPort) • (HDMI) • (HDMI) • (HDMI) • (HDMI) N/A
RS-232 Channel N/A • N/A • • N/A
IR Channel N/A N/A N/A • • N/A
Ethernet Control N/A N/A N/A N/A N/A N/A
PSE: VE802T
POH N/A N/A N/A N/A N/A
PD: VE802R
Scaler N/A N/A N/A N/A • N/A
Ensure high quality maximum distance video transmission with ATEN HDBaseT Cat6 Cable, 2L-2910
Video Extenders - Wall Plates

Connection Cat 5 / Cat 6
Video Interface HDMI DVI VGA
Type US MK / EU US MK / EU US MK / EU
Model VE806 VE807 VE606 VE607 VE156 VE157


Inputs to Outputs 1 to 1
Max. Resolution / 1080p@40m; 1920 x 1200@40m; 1920 x 1200@30m;
Distance 1080i@60m 1280 x 1024@60m 1280 x 1024@150m
Audio • (HDMI / Stereo) • (Stereo) • (Stereo)
RS-232 Channel N/A
IR Channel N/A

Connection HDBaseT
Video Interface HDMI HDMI & VGA
Type US MK / EU US MK / EU
Model VE1801UST VE1801EUT VE2812UST VE2812EUT


Inputs to Outputs 1 Input 2 Input
Max. Resolution / 4K@40m 4K@100m
Distance 1080p@70m 1080p@100m
HDCP 2.2 2.2
Long Reach Mode* N/A • (Active)
Audio • (HDMI) • (HDMI / Stereo)
RS-232 Channel • •
IR Channel N/A •
*Models marked Active provide Long Reach Mode support which can be activated via a switch on the unit. Models marked Passive provide
automatic Long Reach Mode support when activated by another device.
