Versatile Video Walls

ATEN's KVM over IP Matrix Manager (CCKM) allows you to create custom video walls with up to 12 x 12 displays
in various configurations, providing flexible, scalable installations with predefined display content that is easy to
schedule.

Single Source
A source from a single transmitter can be cropped into sections for flexible display configurations:

or ....up to 12x12

Multiple Sources
Multiple sources from multiple transmitters offer unlimited combinations:

Source by TX1 Source by TX3

Source by TX2 Source by TX4

Video Wall Synchronization
The KVM over IP Matrix System’s multicast functionality means it is able to broadcast packets. When the network
switch receives the packets, it simultaneously sends them to all of the designated KVM over IP extenders in the
installation for display:

Scaling
Video
Receiver
Scaling
KVM Video
Broadcasting
Receiver A
Scaling
Transmitter Video
Gigabit Network Switch
with IGMP / ES Series Receiver
Scaling
Video
Receiver
Video KVM Network
