Page 11 - ATEN KVM over IP Matrix System Product Guide
P. 11
Comparison
Model KX9980 KX9970 KE9950 KE9952 KE9900ST KE8980MR KE8950 KE8952
HDMI,
Support Interface DisplayPort DisplayPort DisplayPort DisplayPort DisplayPort HDMI HDMI
DisplayPort
Max. Video 5120 x 1440 5120 x 1440 3840 x 2160 3840 x 2160 1920 x 1200 4096 x 2160 3840 x 2160 3840 x 2160
Resolution @60Hz @60Hz @30Hz (4:4:4) @30Hz (4:4:4) @60Hz @60Hz(4:4:4) @60Hz (4:2:0) @60Hz (4:2:0)
Audio • • • • • (Digital) • • •
Mouse Emulation • • • • • • • •
Tx Local Console • • • • N/A • • •
Boundless Switching • • • • • • • •
Fast Switching* • • • • • • • •
No. of Video Outputs 2 1 1 1 1 4 1 1
Video Wall* • • • • • • • •
RS-232 • • • • • • • •
OSD • • • • N/A • • •
Virtual Media • • • • • • • •
Virtual USB • • • • N/A • • •
PoE N/A N/A N/A • N/A N/A N/A •
DC Jack 2 2 2 1 1 1 1 1
LAN 10 Gbps 10 Gbps 1 Gbps 1 Gbps 1 Gbps 1 Gbps 1 Gbps 1 Gbps
Internet N/A N/A N/A N/A N/A N/A N/A N/A
Network Interface RJ45 (SFP2) RJ45 (SFP2) RJ45 (SFP) RJ45 (SFP) RJ45 RJ45 RJ45 (SFP) RJ45 (SFP)
Model KE8900S KE6900A KE6940A KE6900AiT KE6940AiT KE6920
Support Interface HDMI DVI-I 2*DVI-I DVI-I 2*DVI-I DVI-D
Max. Video 1920 x 1200 1920 x 1200 1920 x 1200 1920x1200 1920x1200 2560x1600
Resolution @60Hz @60Hz @60Hz @60Hz @60HZ @60Hz
Audio • (Digital) • • • • •
Mouse Emulation • • • • • •
Tx Local Console N/A • • • • •
Boundless Switching • • • • • •
Fast Switching* • • • • • •
No. of Video Outputs 1 1 2 1 2 1
Video Wall* • • • • • •
RS-232 • • • • • •
OSD • • • • • •
Virtual Media • • • • • •
Virtual USB N/A • • • • •
PoE N/A N/A N/A N/A N/A N/A
DC Jack 1 2 2 2 2 2
LAN 1 Gbps 1 Gbps 1 Gbps 1 Gbps 1 Gbps 1Gbps
Internet N/A N/A N/A • • N/A
Network Interface RJ45 RJ45 (SFP) RJ45 (SFP) RJ45 (SFP) RJ45 (SFP) RJ45 (SFP*2)
Note: *Supported by KVM over IP Matrix Manager (CCKM)
8
