Page 10 - ATEN KVM over IP Matrix System Product Guide

KE6900A KE6940A
Single Display DVI KVM over IP Extender Dual Display DVI KVM over IP Extender

The KE6900A / KE6940A DVI KVM over IP Extender solution consists of a transmitter that connects to the
computer and a receiver that provides console access from a remote location. This is perfect for use in any type
of installation where you need the KVM console to be placed for your convenience, but you want the computers
to reside in a secure location. Features include:

• Up to 1920 x 1200 @ 60Hz visually lossless and low latency video transmissions
• Ability to route audio, KVM, USB and serial data separately
• The KE6900A supports one DVI-I input/output, while the KE6940A supports two DVI-I inputs/outputs.

KE9900ST / KE8900ST / KE8900SR
Slim DisplayPort / HDMI / DVI-D Single Display KVM over IP Extender

Digital Audio

The KE9900ST / KE8900ST / KE8900SR / models are compact and affordable high performance IP-based
transmitters / receivers, which provide more flexible combinations to build up an over IP solution that enables
users to locate computers in a secure and temperature-controlled environment, away from users’ workstations.
Features include:

• Up to 1920 x 1200 @ 60Hz visually lossless and low latency video transmissions
• Can be paired with any KVM over IP extender for a cost-saving solution that stays within budget
• Space-saving 0U design transmitter can be set on a desk, mounted on a wall or at the rear of a rack

7
